Product Overview

Configurable exit delay is ideal for fail safe environments that have varying needs throughout the day. Function is compatible with entry control, door/lock monitoring,and authorized immediate exit. Widely used in healthcare environments to alert for patient exit and in retail environments to prevent theft.

Standard Features

Meets all code requirements including the BOCA 30 second relock function
Nuisance delay and release times are digitally set using precise DIP switches
Release delay of 15 or 30 seconds
• Three 5A SPDT relays for interface capabilities
External switches such as time clock scan put the XDT into different modes when delayed exit is not desired at all times
MagnaCare® lifetime replacement, no fault warranty

Technical Specifications

100mA at 12vdc, BA-XDT-12 model
50mA at 24vdc, BA-XDT-24 model

Certifications and Listings

UL/cUL FWAX.SA6635 / FWAX7.SA6635
UL Certificate of Compliance (CoC)
CSFM 3774-0923:0102
Underwriter's Laboratories: FWAX Special Locking Arrangements File SA6635
California State Fire Marshal: 3774-0923:0102
City of New York MEA: 251-95E & 254-95E
EMB UL Approval Pending
FWAX2.SA6635 /FWAX8.SA6635
