IPI-30 IP Pro Injector, 30W PoE+ by SDC

The IP Pro is a single door IP controller with expandibility, supporting up to 15,000 users.

Specifications:

• Controls one door directly, with unlimited expansion capabilities
• TCP/IP communications (100/10Mbps)
• DHCP or Static IP addresses
• Password protected built-in webserver (No separate software to install)
• Live transaction monitoring
• Entry & exit reader capability
• Supports industry standard proximity, smart card, and multi-technology readers (Wiegand output)
• Reader short circuit protection
• Compliant with PoE+ standard
• 15,000 users (up to 2 credentials per user)
• Batch card enrollment
• 250 User groups/Time Zones/Door Groups, Holiday support, Scheduled Events
• Temporary Users
• Audit Trail – Up to 5,000 events may be exported as a .csv file
• Status LED’s – Power,Communications, & Fault on-board diagnostic indicators
• Anti-tailgating
• Anti-passback (global or localized)
• Supported browsers: Microsoft Internet Explorer 8 & 9, Firefox 8.0, Google Chrome
• Multiple credential modes: Card only, PIN only, Pin or Card, Pin & Card
• Door Status Monitoring Input
• Request-to-Exit (REX) Input
• Programmable Auxiliary Input
• Lock Relay Output
• Auxiliary Relay Output
• (2) Programmable Solid-state Outputs
• Tamper Input
• Database backup support
