RCI, DKPS-2A Power Supply, 12/24VDC Output 2amp
$360.00
$450.00
Overview
The dormakaba DKPS Series power supply is designed to convert 120-240 VAC, 50 or 60Hz into a continuous 2 Amp supply at 12 or 24VDC power outputs.
Product Details
Product Overview
The dormakaba DKPS Series power supply is designed to convert 120-240 VAC, 50 or 60Hz into a continuous 2 Amp supply at 12 or 24VDC power outputs.
Features
- Selectable 12 or 24VDC output
- 4 voltage outputs, each output max 2.0 A with electronic over-current protection set at 2 Amp
- Status LEDs on enclosure front door (Green, Yellow, Blue)
- FPDB (Fire Panel Disconnect Board) now a standard feature
- Enclosure supports two (2) 12VDC-7 amp-hour (AH) batteries (*batteries sold separately)
Model
- DKPS-2A: Low Voltage Power Supply with Enclosure, 12/24VDC Output 2amp
Specification
- Input: 120-240 VAC, 50 or 60Hz
- Output: 12 or 24VDC, 2amp
- UL294 6th Edition Listed for access control power supply
- CAN/ULC-60839-11-1; CAN/ULC-S533
- FCC Compliant; ISED(IC) compliant
- CE compliance EMC Directive 2014/30/EU
Dimensions
- Metal Enclosure: 13 5/16 inches x 17 5/8 inches x 4 5/16 inches (338mm x 448mm x 110mm)
