20% Off MSRP

Rosslare Security, LK-M12L Magnetic lock with LED Indicator and lock status, 1200lbs

$190.60 ~~$238.25~~

Overview

Rosslare’s LK-M12L high quality magnetic lock is ideal for secure applications where access is restricted, such as office buildings, hospitals and airports.

They have a holding force of 1200 pounds,12/24VDC compatible and easy to install.

Product Overview

Rosslare’s LK-M12L high quality magnetic lock is ideal for secure applications where access is restricted, such as office buildings, hospitals, and airports. They have a holding force of 1200 pounds and are easy to install.

The attractively designed Maglocks are surface mounted, operate on dual voltage, 12 VDC or 24 VDC, and have low current consumption.

These Maglocks are compatible with EN and UL standards.

Features

1200lbs holding force
LED status indicator
Bond status relay: (SPDT)
12/24 VDC input voltage
UL Listed

Model

LK-M12L - Magnetic lock, 1200lbs holding force (includes magnetic lock, armature plate, hardware pack and template)

Specification

Input: 500/250 mA @ 12/24VDC

Dimensions

Magnetic Lock: 10.5 inches L x 2.87 inches H x 1.57 inches D (266 W x 73 H x 40 D mm)
Armature Plate: 7.24 inches L x 2.36 inches H x 0.63 inches D (184 W x 60 H x 16 D mm)

Also Known As

RSP-LKM12L, RSP-LK-M12L

Finish

Aluminum

Manufacturer

Rosslare

Manufacturer Warranty

1 Year

Model Number

LK-M12L

Power Requirements

24VDC/12VDC

Status Monitor

Standard

Usage

Interior Use Only

Datasheet PDF

Installation PDF

1 Question asked on Rosslare Security, LK-M12L Magnetic lock with LED Indicator and lock status, 1200lbs • Ask a Question

Q tom Smallwood • 01/24/2022, 8:35:02 AM Does this unit come with all equipment ready to install and can it be unlock by smartphone?

A 01/24/2022, 2:51:22 PM The LK-M12L is just the magnetic lock, armature plate and hardware pack. It does not include any control devices or a power supply. For a more complete solution, please see our "Access Systems" category where we have a variety of complete kit packages available. To go over any additional questions please give us a call at 1-866-500-5625
